User friendly HMI panel,automatically cut to any length and quantity with pre-setting
•
The pressing die is made from Japanese Steel Grade SKD11 tool steel, then Electrical Discharge Machined to very small tolerance, then hardened to ensure the shape is wrinkle free and sheet metal is not damaged.
•
Rollers are CNC machined to small tolerances, then Chrome plated for durability
•
Siemens PLC ( Japanese PLC available for custom orders)
•
Yuken Hydraulic components
•
Manufactured and assembled in Vietnam
|
Specification
|
C/Ushape
|
V shape
|
Z shape (Louvre)
|
|
Sheet thickness
|
0.4-0.8mm
|
0.3-0.8mm BMT
|
0.2-0.8mm
|
|
Roller speed
|
15-20m/min
|
15-20m/min
|
12-20m/min
|
|
Roller shaft dia
|
φ65mm
|
φ50mm
|
φ60mm
|
|
Motor output
|
10 HP
|
5 HP
|
3 HP
|
|
Roller station (pair up/down)
|
12
|
14
|
10
|
|
LengthxWidthxHeight
|
7x1.5x1.3m
|
5x1.1x1.2m
|
6x0.8x1m
|
|
Net weight
|
6 T
|
2.5 T
|
3.5 T
|
