The C/Z-shape Purline Roll Forming Machine can produce up to 6 different profiles. Each profiles can be altered by manually adjusting the roller gap in 15-30 minutes.
•
User friendly HMI panel,automatically curve to any length and quantity with pre-setting
•
The pressing die is made from Japanese Steel Grade SKD11 tool steel, then Electrical Discharge Machined to very small tolerance, then hardened to ensure the shape is wrinkle free and sheet metal is not damaged.
•
Rollers are CNC machined to small tolerances, then Chrome plated for durability
•
Siemens PLC ( Japanese PLC available for custom orders)
•
Yuken Hydraulic components
•
Manufactured and assembled in Vietnam
|
Specification
|
C shape
|
Z shape
|
|
Sheet thickness
|
1-3mm BMT,G550
|
1-3.5mm BMT,G550
|
|
Roller speed
|
10-12m/min or 18-22m/min, depends on purline profile/shape
|
|
Roller shaft dia
|
φ65-70mm
|
φ70mm
|
|
Motor output
|
15 HP
|
|
Roller station (pair up/down)
|
14
|
|
LengthxWidthxHeight
|
8x1.2x1.3m
|
8x1x1.5m
|
|
Net weight
|
8-10 T
|
7-10 T
|
