Pressure switch

BP-F8

Status: InStock
Manufacturer: ASK
Origin: Japan
Price: We will immediately contact to provide
you our best price guarantee
after receiving your orders

Related equipment

You need help

Tel: (028) 3821 8613 - 3914 0589 - 3821 7012

- Store Address: No. 35, Thu Thiem KDC, 94 TML Street, Thanh My Loi Ward, Thu Duc City, Ho Chi Minh City, Vietnam. city.

Specifications

Product Made In Japan
Manufacture: Act Electric Industry
Model: BP-F8 Series

Features

●Simple pressure setting adjustment.(Setting can be adjust without opening the case)
●Differential pressure adjustment available.
● High-rated current.
●Fine selective pressure range




Hydraulic Fluid: Petroleum base mineral oil.(non-corrosive type)
Partially, air-vapor: water possible
Pressure Range: 050MPa
Connection Port: Rc1/4 for 5MPa, or less / G1/2 for 10MPa. Or above
Optionally, G3/8 available on request
Accuracy: Within ±2% of the max. set pressure range.
Ambient Temp: -20+60°C Fluid Temp.: -20~+70°C
Standard color: Munsell 7.5BG7/2 Case Material: Aluminium die casting.
Permissible Vibration: Up and down 2G/Backward and forward 2G/Right and left 0.8G
Electrical lifecycle: More than 1 million cycles.
Mechanical lifecycle: More than 1 million cycles. Weight: 1.6kg approximately.
