Gauge Valve with Damper

R.T Websites

Gauge Valve with Damper

SAN-200N-2

Status: InStock
Manufacturer: ASK
Origin: Japan
Price: We will immediately contact to provide
you our best price guarantee
after receiving your orders

You need help

Tel: (028) 3821 8613 - 3914 0589 - 3821 7012

- Store Address: No. 35, Thu Thiem KDC, 94 TML Street, Thanh My Loi Ward, Thu Duc City, Ho Chi Minh City, Vietnam. city.

Specifications

For protecting the pressure gauge! A gauge valve with a built-in damper that allows you to freely determine the direction of the pressure gauge!

    • The built-in damper absorbs surge pressure and pulsating pressure in the hydraulic circuit, improving the accuracy and durability of the pressure gauge.

    • It saves space and costs less than installing the damper and gauge valve separately.

    • It has a gauge socket that allows the mounting direction of the pressure gauge to be freely set, so the direction of the pressure gauge can be easily set.

    • Specification

    • Maximum working pressure: 35MPa

    • Pressure resistance: 63MPa

    • Body material: C3771

    • Gauge port recommended tightening torque(※)

      【G1/4：40N・m】【G3/8 and G1/2 ：50N・m】
      * Seal the space between the pressure gauge and the socket of the gauge valve with the attached copper packing.

      　Forcible tightening may cause deformation of the screw part of the main body, which may block the passage of the damper part, so please tighten with the recommended tightening torque.

    • Please refer to the drawing for the shape and dimensions

    Model Gauge screw type G-D Pipe screw type O-ring Copper packing dimension Fluid Weight
    SAN-200N-2 G1/4 Rc1/4 NBR 14.7 x 6 x 2 Petroleum oil 360g
    SAN-200N-3 G3/8 14.7 x 6 x 2 360g
    SAN-200N-4 G1/2 17.8 x 6 x 2 390g
    F-SAN-200N-2 G1/4 FKM 14.7 x 6 x 2 Phosphate ester oil 360g
    F-SAN-200N-3 G3/8 14.7 x 6 x 2 360g
    F-SAN-200N-4 G1/2 17.8 x 6 x 2 390g
    W-SAN-200N-2 G1/4 NBR 14.7 x 6 x 2 Water-glycol based oil 360g
    W-SAN-200N-3 G3/8 14.7 x 6 x 2 360g
    W-SAN-200N-4 G1/2 17.8 x 6 x 2 390g
    SAN-300N-3 G3/8 Rc3/8 NBR 14.7 x 6 x 2 Petroleum oil 360g
    SAN-300N-4 G1/2 17.8 x 6 x 2 390g
    F-SAN-300N-3 G3/8 FKM 14.7 x 6 x 2 Phosphate ester oil 360g
    F-SAN-300N-4 G1/2 17.8 x 6 x 2 390g
    W-SAN-300N-3 G3/8 NBR 14.7 x 6 x 2 Water-glycol based oil 360g
    W-SAN-300N-4 G1/2 17.8 x 6 x 2 390g
