Machine specification
Electric power : 5.5-15kw ( 3 phase , 50Hz , 380v ) .
Weight of machine : 3-5tons .
Machine dimension (L x W x H ) : 3m-9m x 1.5m x 1.8m .
Raw material
Thickness of steel : 0.2mm - 1.0mm (BMT) .
Material : PI/PPGI (galvanize , zincalume , color coating steel)
Max .length : 9.0m
Production specification
Rolling speed : 12-14m/min .(stop cutting and pumching)
Control system of machine : PLC,fully automatic operation
Rolling transmission & Cutting system: By Hydraulic.
Tolerance of lengths : 1mm.
