Pressure gauge

OPG-AT-G-60

Status: InStock
Manufacturer: ASK
Origin: Japan
Price: We will immediately contact to provide
you our best price guarantee
after receiving your orders

You need help

Tel: (028) 3821 8613 - 3914 0589 - 3821 7012

- Store Address: No. 35, Thu Thiem KDC, 94 TML Street, Thanh My Loi Ward, Thu Duc City, Ho Chi Minh City, Vietnam. city.

Specifications

Download Specifications

Type

OPG - A T - G1/4 - 60 x 10MPa
num num num num num num
num Model Glycerin pressure gauge
num Profile A : Frameless
B : Round frame
D : Embedded (with mounting pieces)
num Stub form
T : Square
U （75øD） : 2 surface
S （100ø） : 6 surface
num Screw G1/4 (ø60)
R1/4 (Model A, ø60)
G3/8 (ø75, ø100)
num Dimensions
60 :  ø60mm
75 :  ø75mm
100 :  ø100mm
num Pressure range (maximum indication) See the pressure range table.

Specifications

Applicable fluid General petroleum based hydraulic, water, glycol based hydraulic oil,
phosphate hydraulic oil, water
Accuracy ±1.6%/F.S
Temperature range -5～40℃
Ambient tempreture error ±0.3%/10℃
Sealed liquid Aqueous solution of glycerin
Permissible vibration range 0～7G
Weight 110g
Optional specifications
Color indication
Special indication
(camera-ready copies and negatives can be prepared at an extra charge)
Specifications for cold climates
(temperature range: - 15 to 16 degrees C, silicon oil contained)

Pressure Range Table

Pressure
range		 ø60
A type
G1/4		 ø60
A type
R1/4		 ø60
B type
G1/4		 ø60
D type
G1/4		 ø75
A type
G3/8		 ø75
B type
G3/8		 ø75
D type
G3/8		 ø100
A type
G3/8		 ø100
B type
G3/8		 ø100
D type
G3/8
0.25MPa ○ ※ ※ ※
0.6MPa ○ ○ ○ ○
1MPa ○ ○ ※ ○ ※ ※ ※
1.6MPa ○ ※ ※ ※
2.5MPa ○ ○ ※ ○
4MPa ○ ○ ※ ○ ○ ※ ※ ※ ※ ※
6MPa ○ ○ ※ ○ ○ ○ ○ ※ ※ ※
10MPa ○ ○ ○ ○ ○ ○ ○ ※ ※ ※
16MPa ○ ○ ○ ○ ○ ○ ○ ※ ※ ※
25MPa ○ ○ ○ ○ ○ ○ ○ ※ ※ ※
40MPa ○ ○ ○ ○ ○ ○ ○ ※ ※ ※
60MPa ○ ○ ○ ○ ○ ○ ○ ※ ※ ※
100MPa ※ ※ ※ ※ ※ ※ ※ ※ ※ ※

※Incoming order production

How to use the safety mark (Only ø60mm)

Instruction for use

  • Some combinations of shape, size, and pressure range are not available. Please refer to the type table for making your selection.
  • The glycerin pressure gauge should be mounted vertically; otherwise an indication error or leakage of glycerin liquid may occur.
  • We do not offer glycerin pressure gauge with a special hand-written graduation.
  • Before use, remove the tip of the safety cap of the glycerin pressure gauge up to the 1MPa indication.
  • As there is little torque of the Bourdon tube in pressure gauges of less than 1MPa, When the torque of the Bourdon tube in the pressure gauge up to the 1MPa indication is small, the temperature change (internal pressure change) in the gauge case will affect the indication accuracy. By removing the tip of the safety cap, a balance between the internal pressure and atmospheric pressure can be maintained, thereby preserving accuracy. After removing the safety cap tip, make sure that the safety cap faces upwards to prevent leakage of glycerin liquid.
